Model Numbers
_%25E7%25BB%2593%25E6%259E%259C-1.webp&w=3840&q=80){kind=small}
Application
Prices and pictures are for reference only. Actual quotes will be provided based on specific requirements. We have a professional technical and service team that strives to make everything perfect.
| SPECIFICATIONS | |
| Rig type | CSRC500 Automatic rod change |
| Weight | 12000kg |
| Dimension (transport) | 6300*2100*2500mm |
| Dimension (working) | 4500*3000*6800mm |
| Driling depth | 500m |
| The hole diameter | 105-400 |
| Drill pipe diameter | 76/89/102/114 |
| Drill pipe diameter | 1.5/2.0/3.0m |
| Drilling rod method | Auto |
| Dril head lift force | 300kN |
| Dril head feed force | 150kN |
| Rotary speed RPM | 40-160rpm |
| Max. Torque | 12000N.m |
| Drill head feed force | 3300mm |
| Dril mast slide stroke | 1000mm |
| Hydraulic pumps | 160ml/r. 16MPa |
| Hydraulic cooling system | Air cooling/Water cooling |
| Mechanical winch capacity | 20kN |
| Power unit | 132kw/2200 Cummins 6-cylinder engine |
| Air pressure | 1. 7-3. 5MPa |
| Air consumption | 17-42m° /min |
| Equipped with hammer | Medium and high pressure series |
| Crawler | 12t 400mm Steel |
| Crawler climbing angle | 25° |
| Crawler walking speed | 2-3km/h |
| Note: The above parameters are subject to change without further nouice. Flease refer to the actual product. | |
We offer a variety of reverse circulation drill rigs to meet diverse needs.
*There's the factory-direct sales reverse circulation drill rig with automatic rod handling for faster operations, as well as the automatic rod change system RC drill, a powerful rotary crawler rig for mineral and geotechnical exploration.
*For deep hole mineral exploration, we have the reverse circulation drill rig with air lift and high precision for geotechnical projects. The dual-tube reverse circulation drilling rig excels in rods superior waste extraction with minimal contamination.
*CSRC500 reverse circulation drill rig features automation for precision geotechnical surveys. We also provide an automated crawler-mounted geological exploration reverse circulation drilling rig suitable for deep water wells.
*The 350M RC crawler is a multifunctional reverse circulation drilling rig for water well and ore applications, equipped with pump motor core components. Additionally, there's the reinforced concrete drilling rig equipment, a reverse circulation drilling rig with remote control.
*The 500M RC gas lift reverse circulation drill rig is a hydraulic coring machine with a pump motor, ideal for drilling and coring. Lastly, the RC500 multifunctional crawler reverse circulation drilling rig is powered by a Cummins diesel engine and gear pump, offering new efficient mud air lift for mines.
