Model Numbers
Application
Water-finding instruments are professional devices that locate underground water bodies and analyze their depth and reserves through specific detection principles. They are widely used in scenarios such as well-drilling site selection, agricultural irrigation, and geological exploration, with the core value of improving water-finding efficiency.
Prices and pictures are for reference only. Actual quotes will be provided based on specific requirements. We have a professional technical and service team that strives to make everything perfect.
| Model | ADMT-300AX | ADMT-600AX | ADMT-1200AX | ADMT-3000AX | ADMT-5000AX |
| Maximum Depth (m) | ≤300 | ≤600 | ≤1200 | ≤3000 | ≤5000 |
| Channel Input | 1 Channel MN Input | ||||
| Channel Selection | 1 | ||||
| Optional Depth | 100-300 | 100-600 | 100-1200 | 100-3000 | 100-5000 |
| Depth Layering | 10-100 | ||||
| Connection Method | Serial Port, Wifi, Bluetooth 4.0, USB (with optional 4G Communication） | ||||
| Display Screen | 7-inch IPS Wide-Angle 178° Touch Screen | ||||
| Operating System | Android 13 | ||||
| CPU | RK3568 | ||||
| GPU | Mali G52 | ||||
| Main Functions | Selectable Depth, Real-time 2D/3D Mapping, Removable Battery} | ||||
| Measurement Mode | Mali G52 | ||||
| Frequency Range (HZ) | 1-8K | 1-8K | 0.001-8K | 0.001-8K | 0.001-8K |
| Frequency Selection and Filtering | Preset Frequency Selection and Intelligent Frequency Selection, Analog + Data Filtering with 1-16 Levels Optional} | ||||
| Resolution | 0.1mV±2% | 0.1mV±2% | 0.01mV±1% | 0.01mV±1% | 0.01mV±1% |
| Sampling Time (Second) | 100-360 | 100-360 | 120-1500 | 120-1500 | 120-1500 |
| Battery Power Consumption | 700mA/H | ||||
| Host Weight | 1.6kg | ||||
